An important aspect of the PCC panel becomes evident when the power to the whole facility is fed from one point, from which each feeder is able to deliver a different load type. When manufacturing PCC panels in Ahmedabad, we assess transformer capacity, fault level and diversity factor, as well as connected load. Incoming ACB/MCCB selection is based on actual short circuit calculations and busbar sizing takes into account the amount of temperature rise that will occur inside the enclosure due to continuous operation at high current; this is an expected condition not an unusual one for the busbar.

The arrangement of feeders is done according to operating priority; all utility loads, motor feeders, HVAC supply, and other necessary services will be segregated so that a shutdown in one area will not impact the operation of the entire system. Metering will be located at locations so that the operator can see the parameters without having to open the panel door. The cable alley will be arranged in a way that makes sense, having the least amount of obstruction as site termination is almost never in a straight line.

The internal wiring is structured with proper support for heavy outbound cables. Ventilation, gland plate thickness, and placement of earthing strips have been treated as functional, rather than an accessory. Each PCC panel is subjected to high-voltage testing, functional testing of all circuits, and a verification of protection settings prior to shipping.

In addition, these USA installations of PCC panels are capable of handling imbalance in load sharing, fluctuating voltage, and repeated switching, without overheating or nuisance tripping and providing clear access for maintenance teams to inspect and allow future feeder installation.
