Plc Panel

Once multiple drives, pumps, and field signals become dependent on one control logic (or PLC), the PLC panel becomes the decision point in the entire process. In Ahmedabad, we design PLC panels based on the sequence of operation rather than just the number of I/Os (inputs and outputs). Certain applications require compact panels for water treatment skids; other cases include two types of automation control panels: full-sized with remote I/O and managed Ethernet switches, or those that interface with a SCADA system. Selection of hardware will be based on scan time and communication load plus future expansion, rather than by standard preference.

Internal arrangements are made to maintain signal integrity. PLC modules, power supplies, relays, and network components are mounted with proper segregation from power components. Both analog and digital loops are routed through their own conduits to prevent interference. The proper earthing and termination of shields are taken into consideration because of the potential for unreliable feedback leading to false alarms during live production. The numbering of the field terminals will correspond to the cable schedule so that the commissioning team will have no difficulty in completing testing without repeating the drawings.

Actual operation will be simulated prior to sending meant to/from plant using an HMI so that all motor permissives, valve interlocks, auto-manual logic, and alarm handling will be verified before dispatch. There is room for future I/O cards due to continual plant modifications. Once these PLC panels arrive at US locations onboard they will control continuous process control with stable communication with VFD and MCC panels and provide simple diagnostics for maintenance when equipment fails.
